Core Saws And Blades
Explo Core Saw
SKU: geofactory-explo-core-saw
Contact for price
In stock
This model of slabbing saw, with a diamond blade, is ideal for the mining industry. It ensures precise cutting of geological samples and is easy to move during mining drilling operations. Now built in stainless steel, it offers enhanced durability and corrosion resistance for demanding environments.
The Explo Core Saw is an exclusive design, engineered to slab drill core sections up to 50 cm in length and PQ in diameter. This versatile tool is portable and ideal for both on-site and laboratory applications. It features a powerful tri-phase 5.5 HP motor as standard and includes an efficient recirculating water system for optimal operation.
You can find additional information for this product at the bottom of the page.
If you would like a quote for this product, please contact us by clicking HERE.
The Explo Core Saw is an exclusive design, engineered to slab drill core sections up to 50 cm in length and PQ in diameter. This versatile tool is portable and ideal for both on-site and laboratory applications. It features a powerful tri-phase 5.5 HP motor as standard and includes an efficient recirculating water system for optimal operation.
You can find additional information for this product at the bottom of the page.
If you would like a quote for this product, please contact us by clicking HERE.
Description
This model of slabbing saw, with a diamond blade, is ideal for the mining industry. It ensures precise cutting of geological samples and is easy to move during mining drilling operations. Now built in stainless steel, it offers enhanced durability and corrosion resistance for demanding environments.
The Explo Core Saw is an exclusive design, engineered to slab drill core sections up to 50 cm in length and PQ in diameter. This versatile tool is portable and ideal for both on-site and laboratory applications. It features a powerful tri-phase 5.5 HP motor as standard and includes an efficient recirculating water system for optimal operation.
If you would like a quote for this product, please contact us by clicking HERE.
Additional information:
Material
Stainless steel with aluminium profiles and polycarbonate
Dimensions:
1370 x 780 x 1470 mm / 53.9 x 30.7 x 57.9 inch
Weight:
132 kg / 291 lbs
Power supply:
380-400 VaC, 50 Hz – Three-phases
Motor type:
Arbor size: Ø25.4 mm (1 inch)
RPM:
2750
Range of cutting depth:
From AQ to PQ
Maximum cutting depth:
PQ using a 350 mm blade / 14 inch blade
Maximum cutting length:
500 mm
Diamond blade diameter:
350 mm/ 14 inch
Recirculating fluid system
Pump:
Pump:
Water pump: 1.1 kW / 50 L/min
(no HV Pump for the Explo Core Saw)
Tank capacity:
Standard: 100 L
Decanting tank: 300 L (Optional)
[embed]https://www.youtube.com/watch?v=8BvvHl5dPoQ[/embed]
The Explo Core Saw is an exclusive design, engineered to slab drill core sections up to 50 cm in length and PQ in diameter. This versatile tool is portable and ideal for both on-site and laboratory applications. It features a powerful tri-phase 5.5 HP motor as standard and includes an efficient recirculating water system for optimal operation.
If you would like a quote for this product, please contact us by clicking HERE.
Additional information:
Material
Stainless steel with aluminium profiles and polycarbonate
Dimensions:
1370 x 780 x 1470 mm / 53.9 x 30.7 x 57.9 inch
Weight:
132 kg / 291 lbs
Power supply:
380-400 VaC, 50 Hz – Three-phases
Motor type:
Arbor size: Ø25.4 mm (1 inch)
RPM:
2750
Range of cutting depth:
From AQ to PQ
Maximum cutting depth:
PQ using a 350 mm blade / 14 inch blade
Maximum cutting length:
500 mm
Diamond blade diameter:
350 mm/ 14 inch
Recirculating fluid system
Pump:
Pump:
Water pump: 1.1 kW / 50 L/min
(no HV Pump for the Explo Core Saw)
Tank capacity:
Standard: 100 L
Decanting tank: 300 L (Optional)
[embed]https://www.youtube.com/watch?v=8BvvHl5dPoQ[/embed]
